Detailed Specification

Please note: All imperial measurements are approximate and Palram products are made from metric measurements.

Product Name: 12 x 28 (3.59m x 8.58m) Palram Arcadia 8500 Carport
Assembled Dimensions (Width x Depth): 3.59m x 8.58m (11'9" x 28'1")
Internal Dimensions (Width x Depth): 3.25m x tbc x (10'8" x TBC)
Door Dimensions (Height x Width): N/A
Covering Area: 30.8msq (331.6ftsq)
Storage Area: 14.0msq (150.6ftsq)
Ridge Height: TBC
Eaves Height: TBC
Wind Resistance: 70km/hr (43m/hr)
Snow Load: 80kg/msq (16.4lbs/ftsq)
Light Transmission: 15%
Polycarbonate Panel Thickness: 6mm
Individual Pole Support Thickness: 8cm x 8cm (3" x 3")
Package Dimensions: TBC (Number of packages tbc)
Colour: Grey
Assembly: Self-Assembly
Other Sizes Available: TBC
Manufacturer Guarantee: 10 Year Limited Warranty
EAN Number: 7290108601138
Manufacturer Part Number: 705915
Manufacturer: Palram Applications




If you want to protect a taller vehicle from the elements, the Palram Arcadia Alpine 8500 Carport is an ideal way to achieve this, without the need for a garage. The aluminium legs can be adjusted to a maximum height of 11 feet 7 inches (3.52m), so the carport can easily accommodate vehicles such as motorhomes, vans, 4x4s or caravans.

The Arcadia Alpine 8500 is one of the middle sizes in this range. It measures 12 x 28, so is able to accommodate two small vehicles. This carport has multiple uses and with the extra room, it can also be used as a covered sitting area, providing a space in the shade for you to relax or entertain guests.


Featuring a modern, anthracite grey finish, the Palram Arcadia Alpine 8500 will add a sophisticated touch to your outside space. It is made from heavy-duty aluminium, with laser-cut galvanised steel connectors, making it a remarkably robust structure. This state-of-the-art design provides outstanding weather protection: The Arcadia Alpine 8500 is snow-load tested to 150kg per square metre and wind-resistant to 120 kilometres per hour.

It features bronze-tinted 6mm twin-wall polycarbonate roof panels, that are high-impact, shatter-resistant and built to withstand inclement weather. The panels are also UV protected, which means they will not discolour, fracture, or become brittle over time.

The Arcadia Alpine 8500 requires a solid, level surface onto which to anchor it securely using the supplied footpads. It comes with eight sturdy, aluminium legs that are built to support the weight of the structure and provide plenty of strength and stability, even in harsh weather.

Underpinning its eco-credentials, the carport is made with 100% recyclable materials and has integrated gutter and gutter heads that allow you to easily channel and collect rainwater for a sustainable irrigation system.

Usefully, the structure can easily be disassembled and reassembled in a new location if you need to move it in the future.


Palram produces a range of accessories to ensure you get the most out of your Palram Arcadia, whether you are using it as a covered seating area or as a carport. In the ‘choose additional options section’ you will find accessories designed for use with the Arcadia Alpine 8500 Carport, including a low-heat lighting system and carbon fibre infrared heater.


For added reassurance, this model comes with a Palram 10-year limited warranty at no extra cost. The warrant is conditional on the carport being assembled and maintained in accordance with the manufacturer’s instructions.

Additional Details

The Palram Arcadia Alpine 8500 Carport is delivered flat-packed and will need to be assembled at home. All parts and fixtures needed to construct your Arcadia Carport are provided. Written instructions are provided and should be followed exactly to achieve the safety and security desired from the structure. The structure requires a solid level surface. The assembly process is simple, and the carport requires little ongoing maintenance.

Key Features

  • FREE UK mainland delivery
  • 10-year limited warranty from Palram to ensure your confidence in the long life of the product
  • Protect your vehicles from rain, sun damage, snow, and frost throughout the year
  • A semi-transparent polycarbonate roof provides up to 100% protection from UV rays while allowing some light to be transmitted
  • This polycarbonate will not fracture like glass, or discolour over the years
  • The robust aluminium structure features a grey powder-coated finish and will not rust
  • Laser-cut galvanised steel connectors
  • Manufactured from fully recyclable materials
  • Eight durable aluminium legs that can be adjusted to a maximum height of 11 feet 7 inches (3.52m)
  • A secure anchoring system that uses foot pads to attach the carport to flat driveways
  • Contemporary design with clean lines and polycarbonate technology
  • Relocate the entire structure with ease if needed
  • The built-in guttering system allows you to channel water to water butts or drainage systems
  • This carport is available in a range of sizes.


ALL DELIVERIES ARE DELIVERED TO KERBSIDE OR DRIVEWAY.This product is delivered flat packed, direct to your home and is supplied with a set of instructions to support assembly.

If you have ordered more than one item, they may arrive at different times.

For customers in certain areas (e.g. Scotland and Wales) the timescale may be slightly extended. Please note lead times are counted in working days (Monday to Friday) excluding Bank Holidays.

About the Delivery

Towards the end of the timescale (please refer to the website for your chosen product?s lead time), you will receive notification by the courier that your order has been dispatched. Your order will be delivered by one of the following carriers (we are unable to supply information on which carrier is being used for your order): DX, Panther, DPD or Tuffnells.

If delivery is by DX, it is an all-day service (8am to 6pm), you will be contacted with a text message the working day before delivery confirming your delivery date.

If delivery is by Panther, you will receive a text message the working day before delivery with your delivery date and an estimated two-hour time slot.

If delivery is by DPD, delivery information may come by text or email the working day before delivery. On the day of delivery, you will also be contacted with an estimated one-hour delivery window.

If delivery is by Tuffnells, it is an all-day service (8am to 6pm), you will be contacted by email the working day before delivery.

Please note that both elbec and Palram will be unable to supply any further information on your order during this timescale.

Upon Delivery

Your order will be delivered kerbside or on your driveway. Due to health and safety, and insurance liabilities, the driver will not be able to take your goods to the back of your property but upon request may place the product at the side of the house if there are no access issues. This is to avoid risking damage to your property while delivering to an unsafe location. We will not be able to go through your property.

We recommend against arranging for a third party to install the product before its delivery and checking that all parts are present, and we cannot be held liable for any third-party costs caused by delays.

12 x 28 (3.59m x 8.58m) Palram - Canopia Arcadia Alpine 8500 Carport

NEW - Guarantee - 10 year - gold

Product code - 121012003


Description Information

The Palram Arcadia Alpine 8500 Carport is a modern, multi-purpose structure. It is specially engineered to offer superior, long-lasting protection for taller vehicles. Key features include:

  • An attractive, contemporary design provides enough room for larger caravans and motorhomes. The aluminium legs can be adjusted to a maximum height of 11 feet 7 inches (3.52m), so the carport can easily accommodate taller vehicles
  • Bronze-tinted polycarbonate roof panels that protect your vehicles from rain, snow, hail, and harmful UV-rays
  • A sturdy aluminium frame with integral feet to securely anchor the carport to a suitable solid surface, such as a concrete base
  • Ready to assemble pre-drilled profiles and easy sliding-roof panel assembly, with all screws and anchors included.

View full specification Delivery

Usually delivered: 7-10 Working Days.

Note: Currently not available for delivery to Offshore Post Codes.

excludes installation option

Your choices:

  • 12 x 28 (3.59m x 8.58m) Palram - Canopia Arcadia Alpine 8500 Carport£5,054.00
