Detailed Specification

Please note: all imperial measurements are approximate and Mercia products are made from metric measurements. We would recommend that the base is at least 50mm bigger in each direction.

Product Name: 12 x 10 (3.68m x 3.23m) Mercia Premium Shiplap Apex Workshop
Footprint (Depth x Width): 3.57m x 3.06m (11'9" x 10'0")
Height to Ridge: 2.50m (8'2")
Height to Eaves: 1.79m (5'11")
Walls: 12mm Shiplap Tongue and Groove
Framing: 45mm x 28mm (2" x 1")
Door: Double Doors
Door Opening (Height x Width): 1.67m x 1.20m (5'6" x 3'11")
Door Lock: Hasp and Staple
Roof Type: Apex
Roof: 12mm Tongue and Groove
Roofing Felt: Mineral Roofing Fel
Floor: 12mm Tongue and Groove
Floor Joists: Awaiting information
Floor Joists Direction: Awaiting information
Window(s): 2 Opening Windows
Window / Wall Panels: Window configurations:
Option 1
Both windows on either the left-hand side or the right-hand side depth
Option 2
1 window on the right-hand side depth and the 2nd window on the left-hand depth
(the location of the windows can be decided at the time of assembly)
Window Glazing Material: Styrene
Windowless Option Available: N/A
Treatment: Dip Treated
Portabases Available: N/A
Manufacturer's Guarantee: 10 Year Anti-Rot Guarantee
FSC Certified: Yes
Free Delivery: Yes*
Assembly Available: Optional
EAN Number: 5029442006253
Recommended Treatment: Protek Range (please click here)
Manufacturer: Mercia Garden Products


Combining practicality and versatility, this dip treated 12 x 10 Mercia Premium Shiplap Modular Workshop from Mercia is ideal if you’re looking for something a little more flexible and specific to your needs. Every panel has been intricately designed to be interchangeable to suit you. Want the doors at the back? Easy! Need a window on both sides? Done!

The windows are made of shatter-resistant styrene glazing that can be placed in a configuration of your choice, thanks to the modular design. The roof and floor are constructed with heavy duty 12mm tongue and groove boards, adding to the traditional look of the strong shiplap cladding. It' stronger roof support design with metal bracing adds to its high specification premium finish.  All timber used in this product is FSC® certified. As a workshop, this shed has ample headroom, so you are comfortable as well as secure whilst doing a hobby or some DIY.

Heavy duty roofing felt is also included as standard, which works with the sloped angles of the apex roof to divert rainfall away from your workshop. If security concerns you, the hasp and staple included on the double doors can easily fit a padlock.

Please note: some images may show the workshop decorated with accessories/furnishings these are for display purposes only. These are not included with your purchase.


This product is supplied flat packed with instructions and all the fixings necessary to complete construction. The Mercia Premium Shiplap Apex shed has a ‘modular’ design, which has many advantages. It means that the wall panels of the shed are manufactured in smaller parts, making handling and assembly easier as well as increasing the overall strength of the building.  You've the option of our manufacturer's installation service if you still feel putting the shed together is not the job for you.  We advise against arranging for a third party to install the building before it's been delivered and you've checked that all parts are present, as we cannot be held liable for any third-party costs.

Additional Details about Your Order

If you think that a Mercia Premium Apex Shiplap Workshop would be perfect for you, take a look at our delivery information. If you would like any extra details, feel free to email us to discuss your order and our full range of product options, or better still, give us a call so we can find the perfect shed to suit your needs.

Alternatively, why not visit us at our Brookfields Garden Centre showsite near Nottingham? One of our helpful advisors will be on hand to show you around or to help guide you through your order in person. Though if there is a particular garden building you would like to see, we recommend contacting us in advance to find out if we have it, or one similar, on site.


The shed is supplied untreated except for a factory applied base coat.  This base coat may differ in shade across parts. This dip-treated product requires treatment immediately after assembly, and thereafter annual re-treatment to protect against rotting. There is a 10 year anti-rot guarantee from Mercia, dependant upon the building being treated annually with a wood preservative and a waterproof topcoat.  Our manufacturer recommends Protek Royal Exterior wood paint to protect your shed, you can select your colour choice from the paint options on this page.  Alternatively, if you don't see a colour you like, elbec offer the full range of Protek paints to personalise your garden building.  Click here for the full range of Protek Royal colours.

About Mercia

Mercia Garden Products pride themselves as a British business with over 140 years’ experience. They offer a variety of products ranging from traditional summerhouses and log cabins to greenhouses and fencing and garden storage solutions. All their products are manufactured in the UK using FSC® certified and ethically sourced materials in their products. Mercia focuses on innovating and improving their products whilst maintaining customer satisfaction, including ensuring safety for both customers and staff.

Key Features

  • Free UK Mainland Delivery*
  • 10 year manufacturer’s guarantee
  • Quality shiplap 12mm tongue and groove cladding
  • Heavy duty roofing felt included as standard
  • Ethically sourced FSC certified timber
  • Double doors secured by hasp and staple
  • Tongue and groove boards used for roof and floor
  • 2 opening windows glazed in shatterproof styrene
  • Self-assembly or optional installation service available
  • Modular panel design for customisation
  • All fixtures and fittings included


ALL DELIVERIES ARE DELIVERED TO KERBSIDE OR DRIVEWAY. All of our Mercia products are delivered flat packed other than fence panels (which are delivered fully constructed), direct to your home, and are supplied with a set of instructions to support assembly.

Booking Delivery

You will be required to book your delivery date at the time of placing your order (except for Metal Shed). Our 'Request a Delivery Date' service is available to the majority of areas and you'll find that the majority of the UK postcodes are FREE but some areas may incur a delivery surcharge and some postcodes are not covered at all. Select a 'requested delivery date' by entering your postcode in the 'Request a delivery date' section above. You will also be notified at this time if your area incurs a surcharge or delivery is not covered in your area.

Prior to Delivery

On the morning of your delivery date, you'll be sent an update by text with an estimated 2-hour delivery slot (this update can only be provided where a mobile number has been supplied on the billing address section at the time of checkout) together with a link to the manufacturer delivery portal where you'll be able to track your order.

Please note: Mercia Metal Sheds ONLY - your order is delivered by a courier you will not be notified prior to the delivery. If you are not in on the day of the delivery you will be carded and asked to contact the courier to arrange a new mutual delivery date. The estimated delivery lead time for Mercia's Metal sheds is identified on the product for the metal shed. Lead times are on working days (Monday - Friday) excludes Bank Holidays. These estimated lead times are provided by the manufacturer. Some remote areas will take a little longer.

Upon Delivery

Your order is delivered either kerbside or driveway and will be delivered on either a 3.5T, 7.5T or 18T Lorry. Unfortunately due to health and safety and insurance liabilities the driver will not be able to take your goods around to the back of your property but may upon request place the product at the side of the house if there are no access or restriction issues. We would not risk damaging your property whilst delivering a product to an unsafe location. Unfortunately, we will not be able to go through your property.

We would recommend against arranging for a third party to install the building before it's been delivered and checked that all parts are present, as we cannot be held liable for any third-party costs.


Orders with Assembly

The lead time for our installation option is around 12 weeks from the date of order. With the installation option, the majority of orders will have their delivery and installation on separate days; there will be a small number of orders which will have delivery and installation on the same day. You will be advised by the manufacturer's installation team which category your order falls into.

Depending on the installation option for your order, you will be contacted within the delivery timescale and given a date for either delivery/assembly on the same date or a separate date for delivery and assembly.

12 x 10 (3.68m x 3.23m) Mercia Premium Shiplap Apex Workshop

Was £1999.99 Now £1,599.99
NEW - Guarantee - 10 year - gold

Product code - 20010180


Description Information

The 12 x 10 Mercia Premium Shiplap T&G Modular Workshop is ideal for those who want a garden building that is far more comfortable to spend time in than the average garden shed. Whether you are a keen DIY enthusiast or simply require the ample storage space offered, the workshop boasts a premium build quality at a reasonable price. With a modular design, every panel has been specially designed to be interchangeable to suit you. Key features include:

  • Modular panels, meaning windows and doors can be located wherever you wish; this can also be utilised to give you a “reverse apex” style building layout (see product images)
  • Dip treated that comes with a 10-year anti-rot guarantee for your peace of mind
  • Two opening styrene windows and wide-opening double doors
  • Quality shiplap tongue and groove cladding for a sturdy build and excellent weather protection
